Displacement: 160.2
سم
3
/rev. This is the volume of fluid displaced by the pump in one revolution of the gears.
Rated Pressure: 315 bar. This is the pressure at which the pump is designed to operate continuously under normal conditions.
Maximum Pressure: 350 bar. This is the maximum pressure that the pump can withstand for short periods.
Speed Range: The pump has a recommended speed range of 200 – 3000 rpm. Operating within this range helps ensure the pump's efficiency and reliability.
Flow Rate: At a speed of 1450 rpm, a pressure of 10 bar, and a viscosity of 46
mm
2
/s, the flow rate is approximately 230.4 L/min. The flow rate is directly related to the pump's displacement and speed.
وزن: The approximate weight of the pump is 52 كجم. This information is useful for installation and handling considerations.
