Model Number: F12 – 040 – MF – IV – D – 000
Series: F12 Series
Type: Fixed Displacement Hydraulic Piston Motor
رقم الجزء: 3799525
Performance Specifications
Displacement
Nominal Displacement: The motor has a fixed displacement volume, which for this model might be around 40 cm³/rev (cubic centimeters per revolution). This value determines the amount of hydraulic fluid volume required to turn the motor shaft through one complete revolution and is a key factor in calculating the motor's output torque and speed.
Speed Range
Maximum Speed: The F12 – 040 – MF – IV – D – 000 motor can operate at a maximum rotational speed. This could be in the range of 3000 – 4000 revolutions per minute (RPM), depending on factors such as the pressure, load, and the quality of the hydraulic fluid. The maximum speed is an important consideration for applications where high – speed operation is required.
Minimum Speed: It also has a minimum operating speed, typically around 50 – 100 RPM. Below this speed, the motor's performance might become less stable due to factors like internal friction and the characteristics of the hydraulic system.
Torque Output
Maximum Continuous Torque: The motor is capable of providing a maximum continuous torque output. This could be in the range of 100 – 200 Nm (Newton – meters), depending on the pressure of the hydraulic fluid. The torque output is directly related to the displacement and the pressure difference across the motor.
Peak Torque Capacity: In short – term or intermittent applications, the motor can handle a peak torque that is higher than the continuous torque. The peak torque capacity might be around 120 – 240 Nm for a short duration without causing damage to the motor.
