Type: Mini cycloidal oil motor
نموذج: OMM8, OMM12.5, OMM20, OMM32, OMM40, OMM50, etc.1.
Origin: Mainland China.
Certification: CE certification.
Performance Specifications
Displacement: The displacement range is approximately 8.2 – 50.3 cc/rev.
Speed: The continuous speed can reach up to 1950 rpm, and the intermittent speed is higher.
Pressure: The working pressure is generally in the range of 7 – 10 MPa, and the maximum pressure can reach about 14 MPa.
Torque: The continuous torque is 11 – 46 N·m, and the intermittent torque is higher.
Flow: The continuous flow is 16 – 20 L/min.
