Displacement: 250.5
cm
3
/rev.
Nominal Pressure: 315 bar (for standard fluid). The nominal pressure for special fluids may be different.
Maximum Pressure: 350 bar (for standard fluid, short – term intermittent). The maximum pressure for special fluids is lower.
Speed Range: The minimum speed is 200 rpm, and the maximum speed is 3000 rpm.
Flow Rate: At a speed of 1450 rpm, a pressure of 10 bar, and a viscosity of 46
mm
2
/s, the flow rate is approximately 359.6 L/min.
Weight: Around 60.5 kg.
PGH5 – 3X/100RE11VU2
Displacement: 100.2
cm
3
/rev.
Nominal Pressure: 315 bar (for standard fluid). The pressure may vary for different fluids.
Maximum Pressure: 350 bar (for standard fluid, short – term intermittent). It's lower for special fluids.
Speed Range: The pump operates in the range of 200 – 3000 rpm.
Flow Rate: At the same conditions as above, the flow rate is about 143.8 L/min.
Weight: Approximately 45.5 kg.
