Voith IPV5-32/600 Gear Pump IPVS5-64/101 Hydraulic Oil Pump IPVP6-125

Voith IPV5-32/600 Gear Pump IPVS5-64/101 Hydraulic Oil Pump IPVP6-125

Voith IPV5-32/600 Gear Pump IPVS5-64/101 Hydraulic Oil Pump IPVP6-125

IPV5-32/600 Gear Pump

Port Connections - Suction port: SAE 58.7 x 30.2 mm / AFS 104 G1 1/4"
Pressure port: SAE 47.5 x 22 mm / AFS 100 G3/4"
Peso 15.5 kg
Fluid Compatibility Recommended: Mineral - based hydraulic oil (ISO VG 32 - 68); Other fluids require seal compatibility check
Operating Temperature Range -20°C to +80°C (-4° F a +176 ° F.)

Invia richiesta Chat dal vivo

Dettagli del prodotto

IPV5-32/600 Gear Pump

Displacement per revolution 33.1 cm³/rev
Minimum speed 400 RPM
Maximum speed 3000 RPM
Delivery at 1500 RPM 49.6 l/min
Continuous working pressure 315 sbarra
Peak pressure 345 sbarra

Tag:IPV5-32/600 Gear Pump Voith IPV5-32/600 Gear Pump IPVS5-64/101 Hydraulic Oil Pump IPVP6-125
