Engine Model: D13F
제조업체: Volvo
Engine Type: Diesel engine, designed for a variety of applications including heavy – duty trucks, buses, and industrial equipment.
2. Performance Specifications
Power Output
Rated Power: The rated power of the D13F engine can vary depending on the specific configuration and application. It typically ranges from around 300 kW to 400 kW (400 – 550 horsepower approximately).
Maximum Power: In some boost or high – performance settings, it can achieve a higher peak power for short – duration operations such as overtaking or heavy – load acceleration.
Speed
Rated RPM: The engine usually has a rated speed of around 1600 – 1900 revolutions per minute (RPM). This speed range is optimized for efficient power delivery and fuel economy.
3. Mechanical Specifications
Configuration
Cylinder Arrangement: In – line 6 – cylinder configuration. This design provides good balance and smooth operation.
Bore and Stroke: The bore diameter is typically around 131 mm and the stroke length around 158 mm. These dimensions directly influence the engine's displacement and combustion characteristics.
Displacement: The displacement of the D13F engine is approximately 12.78 liters. Calculated by the formula V = π/4 × (bore)²× stroke × number of cylinders.
무게
Dry Weight: The dry weight of the engine (without coolant, fuel, and oil) is approximately 1000 – 1100 kg. This value can vary depending on additional components or accessories.
Wet Weight: With all fluids (coolant, fuel, and oil) filled to the recommended levels, the weight can increase to around 1200 – 1300 kg.
Dimensions
Length: Approximately 1500 – 1600 mm.
Width: Around 900 – 1000 mm (including external components like manifolds).
Height: Roughly 1100 – 1200 mm. These dimensions are approximate and can vary based on the specific installation requirements and additional equipment attached.
