PVPC-C-3029/1D Piston Pump
| Displacement | – Maximum: 29 cm³/rev
– Variable: 0–29 cm³/rev (adjustable via control mechanism) |
Volume of oil delivered per shaft rotation; variable displacement allows flow adjustment to match system demand (reduces energy waste). |
| Pressure Ratings | – Continuous Operating Pressure: 28 MPa
– Intermittent Pressure: 35 MPa – Peak Pressure (10 seconds max): 40 MPa |
High-pressure tolerance for heavy-duty tasks (e.g., press clamping, excavator lifting). |
| Speed | – Rated Speed: 1,500 rpm (50 Hz) / 1,800 rpm (60 Hz)
– Maximum Speed: 2,400 rpm – Minimum Speed: 600 rpm |
Compatible with standard industrial motors; minimum speed avoids cavitation (air bubble formation in oil). |
| Flow Rate | – Maximum (at 2,400 rpm): ~69.6 L/min (29 cm³/rev × 2,400 rpm ÷ 1,000)
– Adjustable: 0–69.6 L/min |
Flow scales with displacement and speed; variable flow enables precise control of actuator speed (e.g., press ram movement). |
