IPVP6 – 125 – 101
Displacement: 125
cm
3
/rev. This is the volume of fluid that the pump displaces per revolution of its gears.
Rated Pressure: Usually, the rated pressure is around 200 bar. This is the pressure at which the pump is designed to operate continuously under normal conditions.
Maximum Pressure: The maximum pressure that the pump can endure for short periods is approximately 250 bar.
Speed Range: The recommended speed range is 1000 – 2500 rpm. Operating within this range helps to ensure the pump's efficiency and reliability.
Flow Rate: At a speed of 1500 rpm, the flow rate is approximately 187.5 L/min (calculated as displacement × speed).
Power Requirement: Under the rated operating conditions, the power required is about 50 – 60 kW. This power consumption is based on the pump's flow rate, pressure, and overall efficiency.
IPVP5 – 50 – 401
Displacement: 50
cm
3
/rev.
Rated Pressure: The rated pressure is typically 200 bar.
Maximum Pressure: It can reach up to 250 bar for short – term operations.
Speed Range: The speed range is 1000 – 2500 rpm.
Flow Rate: At 1500 rpm, the flow rate is about 75 L/min.
Power Requirement: The power required at the rated operating conditions is approximately 20 – 25 kW.
