OMP80 Hydraulic Motor
| Spostamento (Nominal) | 80 | cc/rev | Matches Eaton 101-3466-009’s displacement |
| Maximum Operating Pressure | 250 | sbarra (3625 psi) | Continuous operation; peak pressure: 315 sbarra (4568 psi) |
| Pressione nominale | 210 | sbarra (3045 psi) | Optimal for long-term reliability |
| Velocità massima | 2800 | RPM | At rated pressure (for fan drive scenarios) |
| Velocità nominale | 1800 – 2500 | RPM | Recommended operating range for fan systems |
| Maximum Torque (Stall) | 125 | N·m (92 lb-ft) | Calculated at peak pressure (315 sbarra) |
| Rated Torque | 105 | N·m (77.4 lb-ft) | Calculated at rated pressure (210 sbarra) |
