1. What is the detailed interpretation of the model “A10VG45DGDM1/10R-NSC10F023S-S”?
| Model Segment | Technical Explanation |
|---|---|
| A10VG | Series Identifier: Axial Piston Variable Displacement Pump (Designed for closed-loop hydraulic systems, industrial-grade heavy-duty performance for mobile and stationary applications) |
| 45 | Nominal Displacement: 45 cm³/rev (cubic centimeters per revolution, indicating the volume of hydraulic fluid displaced per shaft rotation) |
| DGDM1 | Control Type: D = Dual control (pressure + flow); G = Enhanced damping configuration (reduces pressure fluctuations); DM1 = Dual-mode regulation (pressure + flow control with electronic feedback compatibility) |
| 10R | Mounting & Rotation: 10 = SAE 1-bolt flange (complies with SAE J744 Class 1, compact mounting interface); R = Clockwise rotation (viewed from the shaft end) |
| NSC10F023S | Configuration Code: NS = Integrated safety valve; C10 = Relief valve pressure setting (250 bar); F023 = Production batch code; S = Enhanced wear-resistant coating (for harsh working conditions) |
| -S | Supplementary Configuration: Second “S” denotes special sealing design (high-temperature and high-pressure resistant seals) |
2. What are the core technical parameters of the pump?
| Parameter | Specification |
|---|---|
| Nominal Displacement | 45 cm³/rev |
| Maximum Working Pressure | 350 bar (5075 psi) |
| Rated Working Pressure | 315 bar (4568 psi) |
| Maximum Speed | 2800 rpm |
| Minimum Speed | 600 rpm |
| Oil Viscosity Range | 15 – 400 mm²/s (1 mm²/s = 1 cSt) |
| Recommended Oil Temperature | -20°C to +95°C (-4°F to 203°F) |
| Oil Filtration Requirement | ≥ 10 μm (complies with ISO 4406 Class 16/13) |
| Shaft Type | Straight Keyed Shaft (ISO 286-2, Diameter: 35 mm / 1.38 in) |
| Mounting Standard | SAE J744 (1-bolt flange, SAE A) |
| Inlet/Outlet Port Size | Inlet: G1″ (BSPP thread), Outlet: G3/4″ (BSPP thread) |
| Dry Weight | Approximately 38 kg (83.8 lbs) |
| Volumetric Efficiency | ≥ 96% (under rated pressure and speed) |
| Mechanical Efficiency | ≥ 93% (under rated pressure and speed) |
| Control Signal Compatibility | Hydraulic pilot signal (0.8-2.5 bar) + optional 4-20 mA electronic feedback |
