BMER-300-MST4 Cycloidal Hydraulic Motor
Displacement: 300 cc/r (ml/r)
Type: Orbital/Gerotor, high‑speed distribution, low leakage, high torque
Brand/Replacement: Fits White Motor RE series (RE1807030X)
Certification: CE
Key Technical Parameters
Continuous Pressure: 16 MPa (160 bar)
Intermittent Pressure: 20.5 MPa (205 bar)
Peak Pressure: 24 MPa (240 bar)
Continuous Torque: ~873 N·m
Intermittent Torque: ~1119 N·m
Speed Range (Cont.): 10–475 rpm
Max Flow (Cont.): 150 L/min
Mounting Flange: 4‑bolt flange
Output Shaft: Tapered shaft (MST4 = taper + 4‑bolt)
Main Ports: G1/2
Drain Port: G1/4
Weight: ~12 kg
Construction & Advantages
Low Leakage Design: High‑precision gerotor set + advanced flow distribution; commutator runs 6× faster than output shaft for minimal leakage & high volumetric efficiency.
High Torque Density: 300cc displacement delivers 873 N·m continuous torque at low speed, ideal for heavy‑duty wheel drives.
Heavy‑Duty Bearings: Double needle roller bearings handle high radial/axial loads; suited for sweepers, loaders, and rough terrain.
Reinforced Geroler Set: Inlaid‑column stator/rotor; low start pressure, smooth rotation, long life.
High Backpressure Tolerance: Premium shaft seal allows backpressure up to 8 MPa; supports series/parallel circuits.
