Basic Information
- Series: A2FE Fixed‑Displacement Bent‑Axis Plug‑in Hydraulic Piston Pump & Motor
- Main Displacements: 28, 32, 107, 125, 160, 180 cc/rev
- Featured Model: A2FE107/61W‑VZL100
- Pressure Rating: Continuous 35 MPa, Peak 42 MPa
- Features: Low‑speed high‑torque, plug‑in wheel‑mount design, compact structure, high efficiency, wear‑resistant, stable performance
- Application: Concrete mixer drum drive, road roller wheel drive, excavator auxiliary drive, mining machinery, heavy‑duty construction equipment
Basic Information
- Series: A2FE Fixed‑Displacement Plug‑in Bent‑Axis Piston Motor/Pump (Rexroth type)
- Displacements: 28, 32, 107, 125, 160, 180 cc/rev
- Hot‑sale Model: A2FE107/61W‑VZL100
- Pressure: Rated 35 MPa, Peak 42 MPa
- Structure Feature: Plug‑in / wheel‑mount integrated design, low‑speed high‑torque
- Application: Concrete mixer truck drum drive, road roller wheel drive, mining machinery, heavy construction equipment, drilling rig
English FAQ
Q1: What is A2FE107/61W‑VZL100?
It is a 107cc fixed‑displacement bent‑axis hydraulic piston motor, widely used for heavy‑duty plug‑in wheel and mixer drum drive systems.
Q2: Code meaning
- 107: Displacement
- 61W: Version & rotation direction
- VZL100: Port layout, mounting and seal specification
Q3: Advantages
Low‑speed high‑torque, compact plug‑in installation, stable high‑pressure performance, low internal leakage, high efficiency, long service life.
Q4: Compatibility
Fully interchangeable with original Rexroth A2FE series, direct replacement without modification.
