buy Fengchang (Taiwan) MPC-02 MPC-03-W MPC-03-A MPC-03-B sandwich valves pilot-operated check valves MPC-02-W PC-02-A PC-02-B MPC-03-W | Partdic®_excavator hydraulik, Dieselmotor, SKS hydraulisch

Rated Pressure

MPC – 02: 31.5 MPa (about 315 kgf/cm²)

MPC – 03: 31.5 MPa (about 315 kgf/cm²)

Nominal Diameter

MPC – 02: 6 mm (corresponding to 1/4" port size)

MPC – 03: 9 mm (corresponding to 3/8" port size)

Maximum Flow Rate

MPC – 02: 40 L/min

MPC – 03: 80 L/min

Connection Form: Threaded connection

Installation Form: Plate – type installation

Applicable Medium: Oil

Applicable Temperature: 99.9°C (general operating temperature is within the range of normal temperature)

Fluid Type: ISO VG32, 46, 68

Viscosity: 10 – 400 cst (59 – 1854 ssu)

Operating Temperature: – 15 – 70°C (- 5 – 158°F)

Contamination Level: ISO 4406 – 21/19/16, NAS 1638 – 10

Surface Treatment: Zinc phosphate compound

Gewicht

MPC – 03 – A, B: 2.6 kg (5.7 lbs)

MPC – 03 – W: 2.8 kg (6.2 lbs)
