1. What is the detailed interpretation of the model “Al-A10VO100DFR1/31R-VSC62K68”?
| Model Segment | Explanation |
|---|---|
| Al | Custom Prefix: Brand-specific or project-specific identification (optional customization for OEM clients) |
| A10VO | Series Name: Axial Piston Variable Displacement Pump (Industrial-grade, high-pressure series) |
| 100 | Nominal Displacement: 100 cm³/rev (cubic centimeters per revolution) |
| DFR1 | Control Type: D = Dual control (pressure + flow); FR = Hydraulic pilot control with pressure compensation; 1 = Standard control valve version |
| 31R | Mounting & Shaft Configuration: 31 = SAE 3-bolt flange (SAE J744 Class 3); R = Right-hand rotation (viewed from shaft end) |
| VSC62K68 | Additional Specifications: VS = Integrated pressure relief valve; C62 = Relief valve setting (350 bar); K68 = Factory calibration code (optimized for heavy-duty applications) |
2. What are the core technical parameters of this pump?
- Nominal Displacement: 100 cm³/rev
- Maximum Working Pressure: 350 bar (5075 psi)
- Rated Working Pressure: 315 bar (4568 psi)
- Maximum Speed: 2800 rpm
- Rated Speed: 1500 – 2500 rpm
- Minimum Speed: 500 rpm
- Oil Viscosity Range: 10 – 400 mm²/s
- Recommended Oil Temperature: -20°C to +90°C (-4°F to 194°F)
- Oil Filtration Requirement: ≥ 10 μm (ISO 4406 Class 16/13)
- Shaft Type: Tapered keyed shaft (ISO 286-2, diameter: 38 mm / 1.496 in)
- Mounting Standard: SAE J744 (3-bolt flange, SAE B)
- Inlet/Outlet Port Size: Inlet: G1 1/2″ (BSPP), Outlet: G1 1/4″ (BSPP)
- Dry Weight: Approx. 65 kg (143.3 lbs)
3. What are the key performance advantages of this pump?
- Precise Dual Control: Hydraulic pilot pressure-flow compensation (DFR1) enables stepless flow adjustment (0-100%) based on system load, reducing energy waste and improving operational efficiency.
- High Pressure Resistance: Robust cylinder block and piston design (alloy steel material) ensures stable performance at 350 bar max pressure, with volumetric efficiency ≥ 95% and mechanical efficiency ≥ 92%.
- Reliable Protection: Integrated pressure relief valve (VSC62) prevents overpressure damage, adjustable within 100-350 bar; anti-cavitation and anti-shock design enhances durability in harsh working conditions.
- Low Vibration & Noise: Optimized swashplate design and hydraulic damping structure reduce noise to ≤ 80 dB(A) at rated speed, improving operator comfort.
- Wide Operating Range: Adapts to extreme temperatures (-20°C to +90°C) and variable viscosity oils, suitable for both mobile and industrial applications.
- Easy Integration: Standardized mounting dimensions and port sizes ensure compatibility with existing hydraulic systems, facilitating retrofitting and replacement.
