| Nominal Displacement |
28 cm³/rev |
45 cm³/rev |
| Maximum Working Pressure |
350 bar (5075 psi) |
400 bar (5801 psi) |
| Rated Working Pressure |
315 bar (4568 psi) |
350 bar (5075 psi) |
| Maximum Speed |
2800 rpm |
2600 rpm |
| Minimum Speed |
500 rpm |
500 rpm |
| Oil Viscosity Range |
10-400 mm²/s (1 cSt = 1 mm²/s) |
10-400 mm²/s |
| Recommended Oil Temperature |
-20°C to +90°C (-4°F to 194°F) |
-20°C to +90°C |
| Oil Filtration Requirement |
≥10 μm (ISO 4406 Class 16/13) |
≥10 μm (ISO 4406 Class 16/13) |
| Control Signal (Hydraulic Pilot) |
0.8-2.5 bar |
0.8-2.5 bar (pilot pressure) + speed-sensing feedback |
| Shaft Diameter |
30 mm (1.18 in) |
35 mm (1.38 in) |
| Mounting Standard |
SAE J744 (5-bolt flange) |
SAE J744 (5-bolt flange) |
| Inlet/Outlet Port Size |
Inlet: G1″, Outlet: G3/4″ (BSPP) |
Inlet: G1 1/4″, Outlet: G1″ (BSPP) |
| Dry Weight |
Approx. 22 kg (48.5 lbs) |
Approx. 32 kg (70.5 lbs) |
| Volumetric Efficiency |
≥95% (rated conditions) |
≥95% (rated conditions) |
| Mechanical Efficiency |
≥92% (rated conditions) |
≥93% (rated conditions, optimized by speed-sensing) |
