| Nominal Displacement |
100 cm³/rev |
| Maximum Working Pressure |
350 bar (5075 psi) |
| Rated Working Pressure |
315 bar (4568 psi) |
| Maximum Speed |
2800 rpm |
| Rated Speed |
1500 – 2500 rpm |
| Minimum Speed |
500 rpm |
| Oil Viscosity Range |
10 – 400 mm²/s (1 mm²/s = 1 cSt) |
| Recommended Oil Temperature |
-20°C to +90°C (-4°F to 194°F) |
| Oil Filtration Requirement |
≥ 10 μm (complies with ISO 4406 Class 16/13) |
| Control Signal (Hydraulic Pilot) |
0.8 – 2.5 bar (pilot pressure range for flow/pressure adjustment) |
| Shaft Type |
Tapered Keyed Shaft (ISO 286-2, Diameter: 38 mm / 1.496 in) |
| Mounting Standard |
SAE J744 (3-bolt flange, SAE B) |
| Inlet/Outlet Port Size |
Inlet: G1 1/2″ (BSPP thread), Outlet: G1 1/4″ (BSPP thread) |
| Dry Weight |
Approximately 65 kg (143.3 lbs) |
| Volumetric Efficiency |
≥ 95% (under rated pressure and speed) |
| Mechanical Efficiency |
≥ 92% (under rated pressure and speed) |
