Hydraulic Pump/

oem Al-A10vo28ED72/52L-Vsc12n00h Hydraulic Piston Pump A10vo28ED72/52L-Vsc12K68h

oem Al-A10vo28ED72/52L-Vsc12n00h Hydraulic Piston Pump A10vo28ED72/52L-Vsc12K68h

A10vo28ED72/52L-Vsc12n00h Hydraulic Piston Pump

Integrated Safety Protection: Built-in pressure relief valve (set to 350 bar) prevents system overpressure damage; anti-cavitation design enhances reliability in low-inlet-pressure conditions (e.g., long-distance oil supply).
Low Noise & Vibration: Optimized swashplate profile and hydraulic damping structure reduce noise to ≤ 80 dB(A) at rated speed, meeting industrial noise standards and improving operator comfort.
Wide Adaptability: Operates reliably in extreme temperatures (-20°C to +90°C) and variable oil viscosities, suitable for both indoor industrial equipment (e.g., injection molding machines) and outdoor mobile machinery (e.g., excavators).

Parameter	Specification (Applicable to Both Models)
Nominal Displacement	100 cm³/rev
Maximum Working Pressure	350 bar (5075 psi)
Rated Working Pressure	315 bar (4568 psi)
Maximum Speed	2800 rpm
Rated Speed	1500 – 2500 rpm
Minimum Speed	500 rpm
Oil Viscosity Range	10 – 400 mm²/s (1 mm²/s = 1 cSt)
Recommended Oil Temperature	-20°C to +90°C (-4°F to 194°F)
Oil Filtration Requirement	≥ 10 μm (complies with ISO 4406 Class 16/13)
Shaft Type	Tapered Keyed Shaft (ISO 286-2, Diameter: 38 mm / 1.496 in)
Mounting Standard	SAE J744 (3-bolt flange, SAE B)
Inlet/Outlet Port Size	Inlet: G1 1/2″ (BSPP thread), Outlet: G1 1/4″ (BSPP thread)
Dry Weight	Approximately 65 kg (143.3 lbs)
Volumetric Efficiency	≥ 95% (under rated pressure and speed)
Mechanical Efficiency	≥ 92% (under rated pressure and speed)
